Hyundai DHY34KSE Tech Specs:
Dimensions (mm): Length 2200 x Width 950 x Height 1240
Rated Power (kW/kVA): 25 / 31
Max Power (kW/kVA): 28 / 34
Frequency: 50
Voltage(s): 400
Controller: IL-NT MRS 10
ATS Port: INCLUDED
Battery (Ah): 1x12v-60Ah
Fuel Capacity (L): 93
Cooling Fluid Volume (L): 10
Fuel Consumption (l/h): 5.2 / 9.3
Engine Model: HY4102
Power Output (hp): 33
Rotate Speed: 1500 RPM
Speed Regulation: 33
Displacement: MECHANICAL
Alternator: AVR
Power Factor (Cosφ): 0.8
Low Oil Pressure: Yes
Block On Startup: Yes
Low Battery: Yes
High Temperature On Water: Yes
Low Oil Level: Yes
Low Running On Engine: Yes
Emergency Stop: Yes
N.G. (kg.): 890
Noise @ 1m: 92
Noise @ 7m: 65
Capacity (units/container): 6/20GP;12/40GP;12/HQ
Weight: 970kg.
Gross Weight (kg): 970.00
Engine Type: HY4102
No Of Cylinders 4.00
Displacement (CC): 3857.00
Cooling Method Water
Speed (RPM): 1500.00
Voltage Regulation Method: AVR
Rated kVA: 31.00
Max/Cont Current (a) 50/45
Frequenzy (Hz): 50.00
Connection Method(s): 3 x 230V/32A & Busbar
Battery Type (v/Ah): 1 x 12/60
Dimensions L x W x H (mm): 2200 x 950 x 1240
Genesis Gen is the leading Dealer of Perkins, Yanmar, Cummins and Hyundai powered diesel generators in South Africa. And we also offering easy installations.
